DJI Modify Flagship Permanent is DJI’s first intelligent 3D model editing software, delivering the complete Modify feature set — including exclusive Point Cloud Editing and Terrain Result Generation — as a permanent single-device license. Designed for simplicity, intuitiveness, and efficiency, it enables rapid point cloud processing, intelligent mesh repair, and automated terrain generation. When paired with DJI Enterprise drones and DJI Terra, DJI Modify delivers a comprehensive one-stop solution from aerial surveying to final model delivery for surveying and mapping, firefighting, emergency response, and transportation.
Streamlined Interaction – Built for Speed
Simple, Intuitive Operation
DJI Modify features a streamlined interface that requires minimal onboarding. Intuitive controls and practical editing tools reduce manual effort and simplify the entire model editing process — get started rapidly without extensive training.
Efficient Workflow
With no complex settings required, DJI Modify quickly imports and exports model files and performs consistent editing operations — including automatic texture repair and batch vehicle flattening — dramatically reducing modeling workload from start to finish.
High & Low Quality Model Display
DJI Modify supports viewing and editing both high- and low-quality models in a single interface. All changes are synchronized across both models and previewed immediately for a seamless editing experience.
Rich Point Cloud Display Modes
Supports adjustable point size and multiple display modes — RGB, Elevation, Class, Intensity, and Number of Returns — with RGB and Class color overlay for efficient point cloud classification.
Efficient 3D Point Cloud Repair (Flagship Exclusive)
Smart Filter
Automatically differentiates ground, vegetation, buildings, wires, electric towers, vehicles, and dynamic objects in city and multi-building scenes. Quick Selection and Structure Selection tools enable precise post-classification refinement.
Manual Classification
Correct misclassified ground points using Polygon, Rectangular, Brush, or Single Selection tools. Use Tolerance adjustment to quickly select and reclassify point clouds with similar colors in one click.
Point Cloud Processing
- Noise Reduction – Removes isolated noise points and improves overall point cloud quality
- Downsampling – By distance or percentage for flexible point cloud density adjustment
- Smoothing – Eliminates discrete noise to make local structures clearer
Terrain Result Generation (Flagship Exclusive)
Generates accurate Digital Elevation Models (DEM), contours, grids of points, and Triangulated Irregular Networks (TIN) from classified ground point clouds — meeting the requirements of surveying, mapping, and planning workflows.
Efficient 3D Model Repair
Floating Parts Removal
Select and remove floating model artifacts instantly via box selection or single-point selection, with immediate post-removal model preview.
Flattening
Identify and select vehicles by mouse-framing or automatic detection, then flatten all vehicle meshes with one click. DJI Modify automatically smooths textures in flattened areas for a seamless, aesthetically pleasing result.
Texture Repair
- Erase Mode – Matches and repairs selected areas with surrounding patterns automatically
- Clone Mode – Drag a pattern from a source area to repair a target area; DJI Modify seamlessly blends edges with surrounding regions
Hole Fill
DJI Modify automatically identifies and highlights holes in the model. Click or frame hole perimeters to repair them in one click — with automatic texture restoration for excellent blending results.
Water Surface Repair
Draw and adjust water surfaces directly on the model with flexible control over range, height, shape, and position. Fill with texture patterns or custom colors for optimal visual repair of water scenes.
Cloud Sharing & Quick Delivery
- Multiple Export Formats – Supports PLY, OBJ, B3DM, and more, compatible with DJI Terra and leading third-party software
- Instant Cloud Sharing – Share processed models via link for online viewing on web or mobile — no software installation required for recipients
Application Scenarios
- Surveying & Mapping – DEM, TIN, and contour generation from classified point clouds for professional GIS and CAD workflows
- Firefighting & Emergency Response – Rapid 3D scene modeling and sharing for real-time situational awareness and operational planning
- Transportation & Infrastructure – Precise 3D model editing for road, bridge, and infrastructure documentation and management
- Urban Planning – High-quality 3D reality models for smart city development and cadastral surveying
